JDAM-9017F

*Price on request. Contact us for a quote.

Manufacturer: Avalue

Over-voltage protection on analog input
Over-load protection on analog output
10 samples per second
IP Re-Assignment
Standalone control function : step sequence control instruction, device to device
communication

Product Description

The Avalue JDAM-9017F is a compact RS-485 remote digital input/output module equipped with 4 digital inputs and 4 digital outputs, making it ideal for industrial automation applications.

It supports communication speeds of 1200, 2400, 4800, 9600, 19.2K, 38.4K, and 115.2K bps, ensuring compatibility with various systems. Operating with a power requirement of 10Vdc to 30Vdc and a maximum power dissipation of 1.2W, the JDAM-9017F is designed for energy-efficient performance.

Its robust design ensures reliable operation in demanding industrial environments.

Technical Specifications

Power Requirement

Power Consumption

1.4W(max.)

Power Requirement

10Vdc ~ 30Vdc

I/O

Interface

RS-485, 2 wires

Speed(bps)

1200, 2400, 4800, 9600, 19.2K, 38.4K, 115.2K

Digital Input

Input Channel

6 differential + 2 single-ended or 8 differential

Resolution

16-bit /12-bit

Input Range

+/- 150mVdc, +/- 500mVdc, +/- 1Vdc, +/- 5Vdc, +/- 10Vdc and +/- 20mA

Zero Drift

0.03 uV/C

Band width

15.72Hz(normal); 78.6Hz(fast)

Span Drift

25 ppm/C

Over Voltage Protection

+/- 35Vdc

Ordering Information

ACC-AIO-RS-01R

What is JDAM-9017F?

The JDAM-9017F is a industrial & embedded motherboard manufactured by Avalue, designed specifically for motherboard-embedded-peripheral applications. The Avalue JDAM-9017F is a compact RS-485 remote digital input/output module equipped with 4 digital inputs and 4 digital outputs, making it ideal for industrial automation applications. It supports communication speeds of 1200, 2400, 4800, 9600, 19.2K, 38.4K, and 115.2K bps, ensuring compatibility with various systems. Operating with a power requirement of 10Vdc to 30Vdc and a maximum power dissipation of 1.2W, the JDAM-9017F is designed for energy-efficient performance. Its robust design ensures reliable operation in demanding industrial environments.
