Cómo elegir el procesador de su PC industrial embebido

TSL Automation Solutions 28 de enero de 2025 Actualizado el 18 may 2026

Guía de selección de procesador para PC embebido industrial, TSL Automation Solutions

Índice de contenidos

Industrial CPU Tiers: From Low Power to High Performance

CPU Class	TDP	Best For
Intel Atom / Celeron N	4 a 15W	IoT gateways, data loggers, simple HMI
Intel Core i3 / i5 (U-series)	15 a 28W	SCADA workstations, operator panels, MES terminals
Intel Core i5 / i7 (H-series)	45 a 65W	Machine vision, SCADA servers, AI edge inference
Intel Core Ultra / Xeon	55 a 125W	High-performance edge computing, multi-camera vision, AI NPU
AMD Ryzen Embedded	15 a 35W	High-graphics, multi-display applications

Key Processor Considerations for Industrial Embedded PCs

TDP vs fanless cooling, fanless chassis have a heat dissipation limit (typically 15 a 65W); never exceed the chassis TDP rating
Industrial temperature grade, not all Intel Core processors have industrial temperature variants; confirm extended-temp support with your hardware vendor
Long-term availability, industrial embedded processors have 7 a 10 year supply guarantees vs 2 a 3 years for consumer CPUs
Integrated graphics vs discrete GPU, for basic SCADA displays, integrated graphics is sufficient; for machine vision or AI, a discrete GPU may be required

Matching CPU to Application

Simple data logger / IoT gateway → Intel Atom or Celeron N, 6 a 15W fanless
SCADA workstation (1 a 2 screens) → Core i5 U-series, 15 a 28W fanless
Machine vision (single camera) → Core i5 or i7 H-series, 45W fanless or active cooling
Edge AI (NPU + vision) → Intel Core Ultra with integrated NPU or Core i7 + NVIDIA GPU

Preguntas frecuentes

For reliable fanless operation in ambient temperatures up to 50°C, specify processors with TDP of 15W or less (Intel Atom, Celeron N-series, Core i-series low-power variants). For ambient temperatures up to 40°C, 25 a 35W TDP processors (Core i5/i7 embedded U/H-series) are reliably cooled in well-designed fanless enclosures. Processors above 45W TDP generally require active cooling.

Intel Atom processors (x6000E Elkhart Lake series, 6 a 12W TDP) are designed for IoT gateway, edge connectivity, and protocol conversion applications, high I/O integration, low cost, lower performance. Intel Core i5/i7 (25 a 45W embedded-grade) delivers workstation-class performance for SCADA, machine vision, and AI inference. Choose Atom/Celeron for simple data collection; choose Core i5/i7 for demanding real-time processing.

SCADA client and HMI applications typically run well with 4 a 8GB RAM. SCADA servers with large tag databases need 8 a 16GB. Machine vision systems running deep learning models benefit from 16 a 32GB. IoT gateway and protocol converter applications function reliably with 4GB. As a rule, specify more RAM than your application currently requires, it is the cheapest upgrade that prevents future performance bottlenecks.

Industrial embedded PCs should use NVMe SSD (M.2 or 2.5-inch) rather than spinning hard drives. SSDs have no moving parts (critical for vibration resistance), faster boot and application load times, and operate across the full industrial temperature range. Choose industrial-grade SSDs (with power-loss protection and wide temperature ratings) rather than consumer SSDs for production applications.

Yes, TSL Automation Solutions provides application engineering support to help Indian customers select the right Avalue embedded PC processor, memory, and storage configuration for their specific application. Contact our Mumbai team with your software requirements, ambient temperature, and enclosure constraints for a recommendation.
