What are the key features of the RiPac-10P3?

The RiPac-10P3 is an Intel Celeron J3455 10.1" all-in-one mini POS terminal with a 10-point PCAP operator touch screen, a 5" adjustable customer-facing LCD, a built-in 58/80mm SEIKO thermal printer, 4GB LPDDR4 (8GB optional), 128GB eMMC, optional NFC, 4x USB 3.0, an RJ11 cash-drawer port, and 2x powered RS-232 COM ports.

Which processor does the RiPac-10P3 use?

It uses the Intel Celeron J3455 with Intel HD Graphics 500 for efficient POS performance.

Does the RiPac-10P3 have a built-in printer?

Yes, it integrates a SEIKO CAPD347D-E thermal printer supporting 58mm and 80mm paper, 576 dots/line, 200mm/s speed, and full/partial cut.

Does the RiPac-10P3 have a customer display?

Yes, it includes a 5" adjustable customer-facing LCD (1280x720) in addition to the 10.1" 1280x800 operator screen.

How much memory and storage does the RiPac-10P3 have?

4GB LPDDR4 by default (8GB optional) and 128GB onboard eMMC.

Does the RiPac-10P3 support NFC?

Yes, optional NFC supporting ISO/IEC 14443 A/B, 15693, and MIFARE for contactless payment and loyalty.

Can the RiPac-10P3 drive a cash drawer?

Yes, it has an RJ11 (24V) cash-drawer port.

What COM ports does the RiPac-10P3 provide?

2x RS-232 in DB9, each powered with selectable 5/12V for peripherals like scanners and displays.

What wireless does the RiPac-10P3 include?

Built-in 802.11ac Wi-Fi and Bluetooth 4.0 + Class 1.

Is the RiPac-10P3 fanless?

No — it uses a 5200 RPM cooling fan to manage thermals in its compact all-in-one chassis.

What power input does the RiPac-10P3 use?

A +24V DC input via a lockable DC jack in ATX mode, with a 120W (24V@5A) adapter.

What applications is the RiPac-10P3 best suited for?

As a turnkey all-in-one mini POS station with printer, customer display and NFC, it suits retail checkout, hospitality, and quick-service environments.

What are the benefits of using an all-in-one POS terminal?

All-in-one POS terminals reduce clutter, simplify installation, improve reliability, and enhance operational efficiency.

Why is a dedicated POS terminal important for businesses?

Dedicated POS terminals provide reliable performance, better integration with peripherals, and efficient transaction handling compared to general-purpose systems.

Avalue · Panel PC / Monitor / Mobile

RiPac-10P3

Data Sheet

*Price on request. Contact us for a quote.

Manufacturer: Avalue

Highlights

10.1" (1280x800) front operator panel with 10-point PCAP touch
5" (1280x720) adjustable customer-facing LCD
Intel Celeron Processor J3455
4GB LPDDR4 (8GB optional), 128GB eMMC
Integrated 58/80mm SEIKO thermal printer (200mm/s)
Optional NFC (RFID / MIFARE)
4x USB 3.0, RJ11 cash-drawer (24V), 2x powered RS-232 (5/12V)
Built-in Wi-Fi 802.11ac + Bluetooth 4.0
Lockable 24V DC jack; CE / FCC / UKCA / VCCI / CCC

Product Description

The Avalue RiPac-10P3 is an Intel Celeron J3455 10.1" all-in-one mini POS terminal designed as a complete, space-efficient point-of-sale station.

It integrates a 10.1" 10-point PCAP touch operator screen, a 5" adjustable customer-facing LCD, and a built-in 58/80mm SEIKO thermal printer in a single compact unit.

With 4GB LPDDR4 (8GB optional), 128GB eMMC, built-in Wi-Fi/BT, and optional NFC (RFID/MIFARE), it covers full retail workflow.

Connectivity includes 4x USB 3.0, an RJ11 cash-drawer port, and 2x powered RS-232 (5/12V) COM ports, on a lockable 24V DC jack — a turnkey POS station for retail and hospitality.

Technical Specifications

Processor

Intel® Celeron® Processor J3455

System Memory

4GB LPDDR4 (default) / 8GB LPDDR4 (optional)

Storage

Onboard 128GB eMMC

Solid State Drive

128GB eMMC

Graphic Chipset

Intel® HD Graphics 500

Audio Codec

ES8336

LAN Chipset

1 x RJ45 with realtek RTL8111H

DC Input

+24V

DC Input Connector

DC Jack

OS

Win 10

Certification Information

CE/FCC/UKCA/VCCI/CCC

USB Port

4 x USB 3.0

LAN Port

1 x RJ45 10/100/1000

LCD Size

10.1" LCD, 5" LCD (customer side)

Resolution

1280 x 800 (10.1), 1280 x 720 (5)

Touch Type

10 Point projected capacitive touch

COM Port

2 x RS232 in DB9, powered with 5/12V

Cash Drawer

1 x RJ11 (24V)

Printing Method

SEIKO thermal printer CAPD347D-E

Total Dots Per Line

576 Dots

Max. Print Speed

200mm/s

Max. Print Width

72mm

Max. Paper Width

80mm

Type of Paper Cutting

Full cut & partial cut

NFC

ISO/IEC 14443 A/B, 15693, mifare

WLAN

Built-In IEEE 802.11 a/b/g/n/AC

Bluetooth

Built-in bluetooth 4.0 + Class 1

Operating Temp.

0°C ~ 40°C (32°F ~ 104°F)

Storage Temp.

-10°C~60°C

Operating Humidity

40°C @ 95% Relative humidity, non-condensing

Dimension (W x L x H)

(L)299.1 x (W)273.2 x (H)128.8 mm

Weight

3 kg

Vibration Test

1.5 Grms, IEC 60068-2-64, random, 5~500Hz, 30min/axis

Shock Test

10 Grms, IEC60068-2-27, half sine, 11ms

Power Mode

ATX

System Fan

5200RPM fan

Construction - Front

Black/white

Construction - Rear

Black/white

Color

Black & gray / full white

Construction

Plastic

Adapter

Input: 100 ~ 240Vac/ 50 ~ 60Hz

Output: 120W adapter (24V @5A)

Packing List

1 x RIPAC-10P3

1 x Power adapter

Ordering Information

RIPAC-10P3-A1-02R | 10.1"/1280 x 800/J3455/4GB/128GB/2COM/4USB/1LAN/Black

RIPAC-10P3-A1-12R | 10.1"/1280 x 800/J3455/4GB/128GB/2COM/4USB/1LAN/White, EU Power Cord E170203183DR, US Power Cord E1702031835R, JP Power Cord E17120318001R, UK Power Cord E170P060370R

What is RiPac-10P3?

The RiPac-10P3 is a panel pc / monitor / mobile manufactured by Avalue, designed specifically for pos-terminal applications. The Avalue RiPac-10P3 is an Intel Celeron J3455 10.1" all-in-one mini POS terminal designed as a complete, space-efficient point-of-sale station. It integrates a 10.1" 10-point PCAP touch operator screen, a 5" adjustable customer-facing LCD, and a built-in 58/80mm SEIKO thermal printer in a single compact unit. With 4GB LPDDR4 (8GB optional), 128GB eMMC, built-in Wi-Fi/BT, and optional NFC (RFID/MIFARE), it covers full retail workflow. Connectivity includes 4x USB 3.0, an RJ11 cash-drawer port, and 2x powered RS-232 (5/12V) COM ports, on a lockable 24V DC jack — a turnkey POS station for retail and hospitality.

Key Features & Benefits

10.1" (1280x800) front operator panel with 10-point PCAP touch
5" (1280x720) adjustable customer-facing LCD
Intel Celeron Processor J3455
4GB LPDDR4 (8GB optional), 128GB eMMC
Integrated 58/80mm SEIKO thermal printer (200mm/s)
Optional NFC (RFID / MIFARE)
4x USB 3.0, RJ11 cash-drawer (24V), 2x powered RS-232 (5/12V)
Built-in Wi-Fi 802.11ac + Bluetooth 4.0
Lockable 24V DC jack; CE / FCC / UKCA / VCCI / CCC

Applications & Use Cases

The RiPac-10P3 is ideal for various industrial automation applications:

DC-powered industrial installations and mobile applications
Wireless connectivity and remote monitoring applications
Legacy equipment integration and serial communication
High-performance computing and data processing tasks
Interactive control interfaces and operator panels
Peripheral device connectivity and data transfer
Memory-intensive applications and multitasking
Visual monitoring and data display systems
