What is the PCC-APC-AB23-C panel kit used for?

The PCC-APC-AB23-C is an open frame panel kit designed for integrating 23-inch panel PCs or industrial displays into machines, control panels, and embedded industrial systems.

Is the PCC-APC-AB23-C suitable for industrial environments?

Yes, it is designed for industrial environments that require secure, stable, and long-term integration of panel PCs or displays.

What types of systems can be integrated using this panel kit?

This panel kit is suitable for panel PCs, industrial monitors, and HMI systems used in automation, manufacturing, and industrial control applications.

Does the PCC-APC-AB23-C support open frame installation?

Yes, it supports open frame installation, allowing flexible mounting into custom enclosures, kiosks, or machinery panels.

Is this panel kit suitable for OEM and system integrator projects?

Yes, it is well suited for OEMs and system integrators requiring customized panel PC or display integration solutions.

Is the PCC-APC-AB23-C easy to install?

The kit is designed to simplify installation and reduce system integration time during assembly.

What are the benefits of using a panel PC open frame kit?

Open frame panel PC kits provide flexible integration, space efficiency, easier customization, and reliable mounting for industrial applications.

Can this panel kit be used for HMI applications?

Yes, it is suitable for HMI applications where panel PCs or displays are embedded into control panels or machine interfaces.

Is the PCC-APC-AB23-C suitable for automation and manufacturing systems?

Yes, it is suitable for automation, manufacturing, and industrial control systems requiring durable panel integration solutions.

Why are panel kits important in industrial panel PC solutions?

Panel kits ensure secure mounting, proper alignment, and long-term reliability of panel PCs or displays in demanding industrial environments.

PCC-APC-AB23-C

*Price on request. Contact us for a quote.

Manufacturer: Avalue

23.8\" LCD with PCAP Multi-Touch
Wide Operating Temperature Support
Up to 250 nits Brightness with LED Backlight (provide customization for higher brightness)
High Contrast Ratio up to 1000:1
LVDS Signal Interface
With Function Icon & NFC logo Printing In Front
Optical Bonding (Customized Solution)
Anti-reflective, Anti-fingerprint, Anti-glare, Anti-UV Panel Coating (Customized Solution)
Logo Customized Service

Product Description

The Avalue PCC‑APC‑AB23‑C is a 23.8″ Full HD (1920×1080) LCD panel kit featuring a projected‑capacitive (PCAP) multi‑touch interface and LVDS signal interface.

It delivers up to 250 nits brightness (customizable), a 1000:1 contrast ratio, and supports a broad environmental tolerance (panel: 0 °C–50 °C; touch sensor: –30 °C–70 °C).

Additional customization options include optical bonding, anti‑glare / anti‑fingerprint / anti‑UV coatings, and custom logo printing — making it a flexible solution for industrial HMI, kiosks, POS terminals, and embedded systems.

Technical Specifications

Panel

LCD Size

23.8\", 16:9

LCD Panel

LVDS

Display Type

FHD

B/L Inverter/Converter

with LED Driving Board

Resolution

1920*1080

Pixel pitch

0.2745mm(H)×0.2745mm(V)

Luminance

250 nits

Contrast ratio

1000

Viewing angle

89 (U), 89 (D), 89 (L), 89 (R)

Response time

20ms

Touch Type

PCAP

Touch Light Transmission

16 ms

Touch Controller

EETI

Mechanical & Environmental

Operating Temp.

0 to 50℃ (panel)

-30 to 70℃ (touch)

What is PCC-APC-AB23-C?

The PCC-APC-AB23-C is a panel pc / monitor / mobile manufactured by Avalue, designed specifically for panel-kits applications. The Avalue PCC‑APC‑AB23‑C is a 23.8″ Full HD (1920×1080) LCD panel kit featuring a projected‑capacitive (PCAP) multi‑touch interface and LVDS signal interface. It delivers up to 250 nits brightness (customizable), a 1000:1 contrast ratio, and supports a broad environmental tolerance (panel: 0 °C–50 °C; touch sensor: –30 °C–70 °C). Additional customization options include optical bonding, anti‑glare / anti‑fingerprint / anti‑UV coatings, and custom logo printing — making it a flexible solution for industrial HMI, kiosks, POS terminals, and embedded systems.

Key Features & Benefits

23.8\" LCD with PCAP Multi-Touch
Wide Operating Temperature Support
Up to 250 nits Brightness with LED Backlight (provide customization for higher brightness)
High Contrast Ratio up to 1000:1
LVDS Signal Interface
With Function Icon & NFC logo Printing In Front
Optical Bonding (Customized Solution)
Anti-reflective, Anti-fingerprint, Anti-glare, Anti-UV Panel Coating (Customized Solution)
Logo Customized Service

Applications & Use Cases

The PCC-APC-AB23-C is ideal for various industrial automation applications:

Extreme temperature environments and outdoor installations
Interactive control interfaces and operator panels
Interactive kiosk and self-service terminals
Outdoor and high-ambient-light environments
Visual monitoring and data display systems
Industrial control and monitoring systems
Factory automation and process control
Human-machine interface applications
