What is the PCC-ARC-AB15-C-09R panel kit used for?

The PCC-ARC-AB15-C-09R is an open frame panel kit designed for integrating 15-inch panel PCs or industrial displays into machines, control panels, and embedded industrial systems.

Is the PCC-ARC-AB15-C-09R suitable for industrial environments?

Yes, it is designed for industrial environments that require secure, stable, and long-term integration of panel PCs or displays.

What types of systems can be integrated using this panel kit?

This panel kit is suitable for panel PCs, industrial monitors, and HMI systems used in automation, manufacturing, and industrial control applications.

Does the PCC-ARC-AB15-C-09R support open frame installation?

Yes, it supports open frame installation, allowing flexible mounting into custom enclosures, kiosks, or machinery panels.

Is this panel kit suitable for OEM and system integrator projects?

Yes, it is well suited for OEMs and system integrators who require customized panel PC or display integration solutions.

Is the PCC-ARC-AB15-C-09R easy to install?

The kit is designed to simplify installation and reduce system integration time during assembly.

What are the benefits of using a panel PC open frame kit?

Open frame panel PC kits provide flexible integration, space efficiency, easier customization, and reliable mounting for industrial applications.

Can this panel kit be used for HMI applications?

Yes, it is suitable for HMI applications where panel PCs or displays are embedded into control panels or machine interfaces.

Is the PCC-ARC-AB15-C-09R suitable for automation and manufacturing systems?

Yes, it is suitable for automation, manufacturing, and industrial control systems that require durable panel integration solutions.

Why are panel kits important in industrial panel PC solutions?

Panel kits ensure secure mounting, proper alignment, and long-term reliability of panel PCs or displays in demanding industrial environments.

PCC-ARC-AB15-C-09R

*Price on request. Contact us for a quote.

Manufacturer: Avalue

5.6\" LCD with PCAP Multi-Touch
Wide Operating Temperature Support
Up to 450 nits Brightness with LED Backlight (provide customization for higher brightness)
High Contrast Ratio up to 800:1
LVDS Signal Interface
Optical Bonding (Customized Solution)
Anti-reflective, Anti-fingerprint, Anti-glare, Anti-UV Panel Coating (Customized Solution)
Logo Customized Service

Product Description

The Avalue PCC-ARC-AB15-C-09R is a 15.6″ FHD (1920×1080) LCD panel kit featuring projected‑capacitive (PCAP) multi‑touch support and LVDS signal interface.

With up to 450 nits LED backlight brightness, 800:1 contrast ratio, and 85% touch light transmission, it delivers sharp, vivid visuals and responsive touch performance.

The kit supports wide operating temperatures (‑30 °C to 85 °C for the panel, and ‑20 °C to 70 °C for the touch module), making it suitable for harsh industrial, retail, or public‑facing environments.

Optional customizations include optical bonding, anti‑reflection/anti‑fingerprint/anti‑glare/anti‑UV coatings, and personalized logo printing, enabling OEM/ODM flexibility.

Technical Specifications

Panel

LCD Size

15.6\", 16:9

LCD Panel

LVDS

Display Type

FHD

B/L Inverter/Converter

Built-in

Resolution

1920*1080

Pixel pitch

0.17925 (H) x 0.17925 (V)

Luminance

450 nits

Contrast ratio

800

Viewing angle

85 (U), 85 (D), 85 (L), 85 (R)

Response time

13ms

Touch Type

PCAP

Touch Light Transmission

85%

Touch Controller

WEIDA

Mechanical & Environmental

Operating Temp.

-30 to 85℃ (panel)

-20 to 70℃ (touch)

What is PCC-ARC-AB15-C-09R?

The PCC-ARC-AB15-C-09R is a panel pc / monitor / mobile manufactured by Avalue, designed specifically for panel-kits applications. The Avalue PCC-ARC-AB15-C-09R is a 15.6″ FHD (1920×1080) LCD panel kit featuring projected‑capacitive (PCAP) multi‑touch support and LVDS signal interface. With up to 450 nits LED backlight brightness, 800:1 contrast ratio, and 85% touch light transmission, it delivers sharp, vivid visuals and responsive touch performance. The kit supports wide operating temperatures (‑30 °C to 85 °C for the panel, and ‑20 °C to 70 °C for the touch module), making it suitable for harsh industrial, retail, or public‑facing environments. Optional customizations include optical bonding, anti‑reflection/anti‑fingerprint/anti‑glare/anti‑UV coatings, and personalized logo printing, enabling OEM/ODM flexibility.

Key Features & Benefits

5.6\" LCD with PCAP Multi-Touch
Wide Operating Temperature Support
Up to 450 nits Brightness with LED Backlight (provide customization for higher brightness)
High Contrast Ratio up to 800:1
LVDS Signal Interface
Optical Bonding (Customized Solution)
Anti-reflective, Anti-fingerprint, Anti-glare, Anti-UV Panel Coating (Customized Solution)
Logo Customized Service

Applications & Use Cases

The PCC-ARC-AB15-C-09R is ideal for various industrial automation applications:

Extreme temperature environments and outdoor installations
Interactive control interfaces and operator panels
Outdoor and high-ambient-light environments
Visual monitoring and data display systems
Industrial control and monitoring systems
Factory automation and process control
Retail and point-of-sale applications
Machine control and visualization
