Is the PCC-PPC-AB15-R a complete monitor or a kit?

It is a panel kit (display + touch + driving electronics), not a finished monitor — it is intended to be integrated by the OEM into a kiosk, instrument, or HMI enclosure.

What is the resolution of the PCC-PPC-AB15-R?

1024 x 768 (XGA) on a 15" 4:3 panel.

What touch technology does the PCC-PPC-AB15-R use?

5-wire resistive touch with an EETI touch controller and 80% touch light transmission.

How bright is the PCC-PPC-AB15-R?

Up to 300 nits as standard, with customization available for higher brightness.

What is the contrast ratio of the PCC-PPC-AB15-R?

Up to a very high 2000:1, with 88° viewing angles in all four directions.

What signal interface does the PCC-PPC-AB15-R use?

An LVDS signal interface with a built-in B/L inverter/converter.

What is the operating temperature range of the PCC-PPC-AB15-R?

-20 to 70°C for the panel and -10 to 70°C for the touch — a wide range suited to industrial use.

Can the PCC-PPC-AB15-R be optically bonded?

Yes, optical bonding is available as a customized solution to improve readability and durability.

What panel coatings are available for the PCC-PPC-AB15-R?

Anti-reflective, anti-fingerprint, anti-glare, and anti-UV coatings are available as customized solutions.

Does Avalue offer logo customization on the PCC-PPC-AB15-R?

Yes, a logo customization service is available.

Why choose resistive touch on the PCC-PPC-AB15-R?

5-wire resistive touch works with gloves and styluses and is robust in industrial settings where contaminants or PPE are common.

What is the viewing angle of the PCC-PPC-AB15-R?

88° in all four directions (up, down, left, right).

What applications is the PCC-PPC-AB15-R best suited for?

OEM integration into kiosks, instruments, machine HMI, and embedded display front-ends needing a high-contrast 15" XGA resistive touch module.

What type of systems can use this panel kit?

The kit is suitable for panel PCs, industrial displays, HMI systems, and embedded control interfaces used in automation and machinery.

Can this panel kit be used for OEM projects?

Yes, it is well suited for OEM and system integrator projects requiring customized panel PC or display integration.

Is the panel kit easy to install and integrate?

The kit is designed to simplify installation and integration, reducing assembly time during system deployment.

What are the benefits of using a panel PC open frame kit?

Open frame panel kits offer flexibility, space efficiency, easier customization, and seamless integration into industrial equipment.

Can this kit be used in automation and manufacturing environments?

Yes, it is designed for automation, manufacturing, and industrial control environments requiring durable panel integration solutions.

Why are panel kits important in industrial panel PC solutions?

Panel kits enable secure mounting, proper alignment, and reliable integration of panel PCs or displays, ensuring long-term performance in industrial systems.

Avalue · Panel PC / Monitor / Mobile

PCC-PPC-AB15-R

Data Sheet

*Price on request. Contact us for a quote.

Manufacturer: Avalue

Highlights

15" (4:3) XGA (1024x768) LCD panel kit with 5-wire resistive touch
LVDS signal interface, built-in B/L inverter/converter
Up to 300-nit brightness (higher on request)
Very high contrast ratio up to 2000:1
Wide operating temperature (panel -20~70°C, touch -10~70°C)
EETI touch controller, 80% touch light transmission
Optical bonding (customized solution)
Anti-reflective / anti-fingerprint / anti-glare / anti-UV coatings (customized)
Logo customization service

Product Description

The Avalue PCC-PPC-AB15-R is a 15" (4:3) LCD panel kit with 5-wire resistive touch, supplied as an integration-ready display module with an LVDS signal interface and a built-in B/L inverter/converter.

It is built for OEM integration into kiosks, instruments, and HMI enclosures.

The 1024x768 XGA panel supports up to 300-nit brightness with a very high 2000:1 contrast ratio and a wide -20~70°C panel operating range.

Customized options include optical bonding, higher brightness, anti-reflective/anti-fingerprint/anti-glare/anti-UV panel coatings, and logo customization.

Technical Specifications

LCD Size

15", 4:3

LCD Panel

LVDS

Display Type

XGA

B/L Inverter/Converter

Built-in

Resolution

1024 x 768

Pixel pitch

0.297mm (H) x 0.297mm (V)

Luminance

300 nits

Contrast ratio

2000

Viewing angle

88 (U), 88 (D), 88 (L), 88 (R)

Response time

16 ms

Touch Type

5-wire Resistive Touch

Touch Light Transmission

80%

Touch Controller

EETI

Operating Temp.

-20 to 70℃ (panel)

-10 to 70℃ (touch)

Customized Options

Optical Bonding

Higher brightness

Anti-reflective / Anti-fingerprint / Anti-glare / Anti-UV panel coating

Logo customized service

What is PCC-PPC-AB15-R?

The PCC-PPC-AB15-R is a panel pc / monitor / mobile manufactured by Avalue, designed specifically for panel-kits applications. The Avalue PCC-PPC-AB15-R is a 15" (4:3) LCD panel kit with 5-wire resistive touch, supplied as an integration-ready display module with an LVDS signal interface and a built-in B/L inverter/converter. It is built for OEM integration into kiosks, instruments, and HMI enclosures. The 1024x768 XGA panel supports up to 300-nit brightness with a very high 2000:1 contrast ratio and a wide -20~70°C panel operating range. Customized options include optical bonding, higher brightness, anti-reflective/anti-fingerprint/anti-glare/anti-UV panel coatings, and logo customization.

Key Features & Benefits

15" (4:3) XGA (1024x768) LCD panel kit with 5-wire resistive touch
LVDS signal interface, built-in B/L inverter/converter
Up to 300-nit brightness (higher on request)
Very high contrast ratio up to 2000:1
Wide operating temperature (panel -20~70°C, touch -10~70°C)
EETI touch controller, 80% touch light transmission
Optical bonding (customized solution)
Anti-reflective / anti-fingerprint / anti-glare / anti-UV coatings (customized)
Logo customization service

Applications & Use Cases

The PCC-PPC-AB15-R is ideal for various industrial automation applications:

Extreme temperature environments and outdoor installations
Interactive control interfaces and operator panels
Interactive kiosk and self-service terminals
Outdoor and high-ambient-light environments
Visual monitoring and data display systems
Industrial control and monitoring systems
Factory automation and process control
Human-machine interface applications
