Product Datasheet
20 May 2026
AI Computing Platforms · NVIDIA-Solution
AIB-NINX-S
Series: AIB
Manufactured byAvalue
The Avalue AIB-NINX-S is a compact, fanless edge AI platform built on the NVIDIA Jetson Orin™ NX (8GB/16GB) module, delivering up to 70/100 TOPS for vision and inference at the edge. With 8/16GB 128-bit LPDDR5 (102.4GB/s), 128GB storage and triple M.2 M-Key PCIe Gen4 slots, it pairs rich camera and serial I/O with a rugged fanless design. It provides 4x USB 3.2 Gen2 Type-A, dual HDMI 2.0, 8 internal MIPI CSI-2 lanes, RS-232/RS-485, audio in/out and a wide 9~36V (or 48V PSE) input over a 0~60°C range, running Ubuntu 20.04/22.04 with JetPack 5.1.1 / 6.2, in a 286 x 144 x 76.6 mm, ~1.85kg enclosure.
Key Features
- Compact fanless edge AI platform, NVIDIA Jetson Orin™ NX 8GB/16GB
- Up to 70/100 TOPS AI performance
- 8/16GB 128-bit LPDDR5 (102.4GB/s), 128GB storage
- 3 x M.2 M-Key PCIe Gen4 (x4 / x2 / x1) slots
- 4 x USB 3.2 Gen2 Type-A + 2 x USB 3.2 Gen1 header
- 2 x HDMI 2.0, 8 internal MIPI CSI-2 lanes
- RS-232 / RS-485, audio in/out, 1 x GbE
- DC 9~36V or 48V PSE input, 0~60°C with airflow
- Ubuntu 20.04/22.04, JetPack 5.1.1 / 6.2
Technical Specifications
System Information
| NVIDIA Platform | NVIDIA Jetson Orin™ NX 8GB/16GB |
|---|---|
| AI Performance | 70/100 TOPS |
| System Memory | 8/16GB 128 bit LPDDR5 102.4GB/s |
Development Environment
| OS | Ubuntu 20.04 / Ubuntu 22.04 |
|---|---|
| Kernal | 5.10.104 tegra or Higher |
| BSP | Linux for Tegra(L4T) R35.3.1 or Higher |
| SDK | JetPack 5.1.1 / JetPack 6.2 or Higher |
| AI SDK GitHub | https://github.com/Avalue-Technology/repositories.directory |
Storage
| M.2 | 128 GB |
|---|---|
| Storage | Supports External NVMe |
I/O
| USB Port | 4×USB3.2 Gen2 ( Type-A ), 2×USB3.2 Gen1 ( Pin Header ) |
|---|---|
| LAN Port | 1 x RJ45 for 10/100/1000Mbps Ethernet ( DHCP Client ) |
| HDMI | 2 x HDMI2.0 |
| MIPI (Internal) | 8 MIPI CSI 2 Lanes ( D PHY 2.1, Support MIPI Camera, Capture Card ) |
| Antenna | 4 x Antenna Mounting with Dust Protection Cover |
| AC/DC Input | 1 x DC Jack |
| Audio | 1×3.5mm Line In, 1×3.5mm Line Out |
| RS232 | 1×RS232 ( Phoenix Connector) |
| RS485 | 1×RS485 ( Phoenix Connector) |
| SIM Card Slot | Optional |
Expansion
| M.2 | 1×M.2 2280/3080 M Key PCIe Gen4×4 Slot, 1×M.2 2280 M Key PCIe Gen4×1 Slot, 1×M.2 2280 M Key PCIe Gen4×2 Slot (HDMI 2.0 Model) |
|---|
Mechanical & Environmental
| Power Requirement | DC input : 9~36V / DC Input : 48V (PSE model) |
|---|---|
| Operating Temperature | 0~60C° with Airflow |
| Storage Temperature | -20~70 C° |
| Dimension (W x L x H) | 286mm × 144mm × 76.6mm |
| Weight | 1850g |
Ordering Information
| Ordering Information | AIB-NINX-S08B-A1R:Orin NX 8GB/128GB SSD/Ubuntu 20.04, Jetpack 5.1.1 or JetPack 6.2 / HDMI 2.0, AIB-NINX-S16B-A1R:Orin NX 16GB/128GB SSD/Ubuntu 20.04,Jetpack 5.1.1 or JetPack 6.2 / HDMI 2.0, AIB-NINX-S08E-A1R:Orin NX 8GB/128GB SSD/Ubuntu 20.04,Jetpack 5.1.1 or JetPack 6.2 / PSE, AIB-NINX-S16E-A1R:Orin NX 16GB/128GB SSD/Ubuntu 20.04,Jetpack 5.1.1 or JetPack 6.2 / PSE, AIB-NINX-S08X-A1R:Orin NX 8GB/128GB SSD/Ubuntu 20.04,Jetpack 5.1.1 or JetPack 6.2, AIB-NINX-S16X-A1R:Orin NX 16GB/128GB SSD/Ubuntu 20.04,Jetpack 5.1.1 or JetPack 6.2 |
|---|
Optional Product Features Extension by Daughter Board
| SDK / Software | By request |
|---|---|
| NX 5G | 5G Mobility Network ( Supports 5G / 4G / 3G SIM Module) |
| NX PSE | "*IP Camera, 4×RJ45 for 10 / 100 / 1000Mbps Ethernet with IEEE802.3af Compliant, *PSE Power Supply, 4×15W ( IEEE802.3af )" |
