Product Datasheet
20 May 2026
Computer-on-Module · SMARC
SMA-IMX6-E1
Series: SMA
Manufactured byAvalue
The Avalue SMA-IMX6-E1 is a SMARC (82 x 50 mm) Computer-on-Module built on the NXP i.MX 6 (Dual 800MHz / Quad 1.0GHz) processor, designed as a rugged, long-lifecycle connectorised compute core for industrial and IoT designs. With 4GB DDR3L and 8GB eMMC, it delivers reliable Arm compute through the standardised SMARC connector running Android 4.4.2, Ubuntu 12.04 or Yocto 1.5.1. It exposes SATA, triple PCIe x1, dual CAN, triple I2C/I2S, SDIO, SPDIF, dual SPI, MLB150, JTAG and 12x GPIO over a wide -40~85°C range.
Key Features
- SMARC Computer-on-Module (82 x 50 mm)
- NXP i.MX 6 Dual 800MHz / Quad 1.0GHz
- 4GB DDR3L, 8GB eMMC
- 1x SATA, 3x PCIe x1, 2x CAN
- 3x I2C, 3x I2S, SDIO, SPDIF, 2x SPI, MLB150, JTAG
- 12x GPIO, watchdog timer
- Wide -40~85°C operating
- Android 4.4.2 / Ubuntu 12.04 / Yocto 1.5.1
- CE, FCC Class B
Technical Specifications
System Information
| Processor | NXP i.MX 6 Dual 800M Hz, NXP i.MX 6 Quad Core 1.0G Hz |
|---|---|
| System Memory | 4GB DDR3L |
Storage
| Storage | 8GB eMMC |
|---|
Software Support
| OS | Android 4.4.2, Ubuntu 12.04, Yocto 1.5.1 |
|---|
Certification
| Certification Information | CE, FCC Class B |
|---|
I/O
| External I/O Connector | 2 x CAN, 12 x GPIO, 3 x I2C, 3 x I2S, 1 x JTA, 1 x MLB150, 3 x PCIex1, 1 x SATA, 1 x SDIO, 1 x SPDIF, 2 x SPI, 1 x WDT |
|---|
Mechanical & Environmental
| Operating Temp. | -40°C ~ 85°C (-40°F ~ 185°F) |
|---|---|
| Storage Temp. | -40°C ~ 85°C (-40°F ~ 185°F) |
| Operating Humidity | 0% ~ 90% Relative Humidity, Non-condensing |
| Weight | 0.06kg |
| Power Requirement | DC 3~5V |
| Dimension (L x W) | 82 x 50 mm |
Ordering Information
| Ordering Information | SMA-X6DI3EH-E3R00 : SMA-X6DI3EH-E3R00, SMA-X6QI3EH-E3R00 : SMA-X6QI3EH-E3R00, SMA-X6QI3EJ-E3R00 : SMA-X6QI3EJ-E3R00 |
|---|
