SPC-10W35

Series: SPC

Manufactured byAvalue

The Avalue SPC-10W35 is a 10.1" WXGA stainless-steel fanless industrial touch panel PC built for hygienic, washdown environments, powered by the Intel Celeron J6412 (Elkhart Lake) processor. With sealed M12 waterproof connectors and onboard TPM 2.0 on the ECM-EHL3 SBC, it is engineered for food, beverage, and pharmaceutical line-side computing in a compact form. The 1280x800 16:10 panel offers a bright 500 cd/m² display and 10-point projected-capacitive touch. A single DDR4 3200MHz SO-DIMM supports up to 32GB, with triple M.2 expansion (Key-E Wi-Fi, Key-B with SIM for WWAN+GNSS/SSD, Key-M PCIe) and dual Intel I210 Gigabit Ethernet over sealed M12 connectors. Waterproof M12 USB, LAN, COM and power connectors with covers and chains, and a wide +12~24V input make the SPC-10W35 a durable compact hygienic HMI on Windows or Linux.

Key Features

10.1" WXGA (1280x800) 16:10, 500-nit, PCAP 10-point multi-touch
Stainless-steel washdown design with sealed M12 connectors
Intel Celeron J6412 (Elkhart Lake), ECM-EHL3 SBC
1 x DDR4 3200MHz SO-DIMM, up to 32GB (non-ECC)
Onboard TPM 2.0
Triple M.2: Key-E (Wi-Fi), Key-B (SIM, WWAN+GNSS/SSD), Key-M (PCIe)
Dual Intel I210AT Gigabit Ethernet via sealed M12
Waterproof M12 USB / LAN / COM / power connectors
Wide +12V ~ +24V input, fanless; CE / FCC Class B

Technical Specifications

System Information

Processor	Intel® Celeron® J6412 Processor (1.5M Cache, up to 2.60 GHz)
System Memory	1 x 260-pin DDR4 3200MHz SO-DIMM Socket, Supports Up to 32GB Max. (non ECC only)
I/O Chipset	EC iTE IT5571
Watchdog Timer	H/W Reset, 1sec. ~ 65535sec and 1sec. or 1min./step
H/W Status Monitor	CPU & system temperature monitoring Voltages monitoring
TPM	TPM 2.0
SBC	ECM-EHL3 A1 J6412 Lite
CPU Cooler (Type)	Fanless heatsink

Expansion

Expansion	M/B with 3 M.2 slot:, 1 x M.2 Type E 2230 supports WiFi module (PCIe x1 & USB 2.0 Signal), 1 x M.2 Type B 3042/2242, standard package with 3042 to 3052 bracket + screw set (with SATA and USB 3.0/USB 2.0, with 1 x SIM card slot, supports WWAN+GNSS or SSD), 1 x M.2 Type M supports 2260 slot, standard package with 2260 to 2242 bracket + screw set (with 1 x PCIe x1 signal)

Storage

Other Storage Device	1 x M.2 Type B 3042/2242 slot for M.2 SSD

Ethernet

LAN Chipset	2 x Intel® I210AT (Co-lay I210IT/I211AT) Gigabit Ethernet
Ethernet Interface	2 x M12 4-pin(D-coded female) for LAN with waterproof cover and chain

Power Requirement

DC Input	+12V ~ +24V
Power Mode	ATX mode
Power Connector Type	1 x M12 4-pin (male) for DC power with waterproof cover and chain

Software Support

OS	Win10 / Linux

Certification

Certification Information	CE / FCC Class B

Panel

LCD Size	10.1", 16:10
Display Type	WXGA
Resolution	1280 x 800
Pixel pitch	0.1695mm(H) x 0.1695mm(V)
Luminance	500 cd/m2
Contrast ratio	800
Viewing angle	89 (U), 89 (D), 89(L), 89 (R)
Response time	29 ms
Backlight	LED
Touch Type	Projective capacitive multi-touch up to 10 points
Touch Light Transmission	85%
Touch Controller	EETI

External I/O

USB Port	2 x Waterproof USB 2.0(plastic USB-socket) with waterproof cover and chain
LAN Port	2 x M12 4-pin(D-coded female) for LAN with waterproof cover and chain
COM Port	1 x M12 8-pin (male) COM1(RS-232) with waterproof cover and chain
Switch	1 x Power Switch on the back

Internal I/O

SATA	1 x SATA III

Mechanical & Environmental

Operating Temp.	0℃ ~ 40℃
Storage Temp.	0℃ ~ 60℃
Operating Humidity	10% to 85%, non condensing
Dimension (W x L x H)	295.4 x 213.4 X48 mm
Weight	3.5 Kg
Vibration Test	DIN EN 60068-2:2008, Frequency range: 10~150 Hz, Amplitude: 0,15mm bzw. 2g, Gradient: 1 Okt/min, Test duration: 20 Cycles per axis(40 sweeps), Axis: 3 (X,Y,Z)
Shock Test	DIN EN 60068-2-27:2010, Shock: 15g / 6ms, Form: Semi-sinus, Quantity: 4.000 per direction and axis (+-X;+-Y;=-Z;24.000 total)
Drop Test	Package drop test, Reference ISTA 2A, Method : IEC-60068-2-32 Test:Ed, Test Ea : Drop Test, 1 Test phase : One corner, three edges, six faces, 2 Test high : 96.5cm, 3 Package weight : 5Kg, 4 Test drawing
IP Rating	Front IP65 / Rear IP54
Mounting Kit	Wall / Stand / VESA 100mm x 100mm
Power Mode	ATX
System Fan	Fanless
Construction - Front	Sheet metal, SECC + black painting, matt finish
Construction - Rear	Sheet metal, SECC + black painting, matt finish

Ordering Information

Ordering Information	M12 external M12 DC-in cable (TBD), ACC-ADP-060N-09R \| AC/DC adapter 24V/2.5A 90 Plug Type, E1702031833R \| USA Power Cord, E1702031000R \| EU Power Cord, E1702031834R \| Japan Power Cord, E1702031830R \| UK Power Cord, E1702031831R \| Australia Power Cord
