Panel PC / Monitor / Mobile · Industrial-Panel-PC
eLITE610
Series: eLITE
The Nexcom eLITE610 is a cost-efficient 10.1" widescreen (WSVGA, 1024 x 600) HMI panel PC powered by the Intel Atom x5-E3930 SoC and a 16:9 TFT display with LED backlight dimmable down to 0%. Designed as a slim, plastic-chassis terminal for factory and building automation, the eLITE610 ships preloaded with the JMobile HMI runtime and is fully compatible with JMobile Studio for SVG-based vector graphics, multilanguage applications, data acquisition, alarms, schedulers, recipes, user management, e-mail and RSS feeds, VNC-based remote maintenance and a powerful scripting language with debugging. Connectivity includes two Gigabit LAN ports, two USB 3.0 ports and one BIOS-configurable RS-232/422/485 serial port covering most building and machine automation buses, with optional plug-in modules for fieldbus systems. The 240 cd/m² TFT panel and resistive touchscreen are paired with a true-flat front protected to IP66 (IP20 rear), a wide 19.2–28.8 V DC input and a mounting depth under 30 mm for panel or VESA installation. CE-marked (EN 61000-6-4 emissions / EN 61000-6-2 immunity for industrial environments) and FCC-tested, the eLITE610 is sized for machine control and monitoring, robot interface terminals, SCADA stations and integration into long-life factory or building automation projects. TSL Automation supplies the Nexcom eLITE610 worldwide.
Key Features
- 10.1" widescreen WSVGA (1024 x 600) TFT panel, 16:9, 16.7M colours, 240 cd/m² typ.
- Resistive touchscreen with LED backlight dimmable to 0%
- Intel Atom x5-E3930 (Apollo Lake) SoC, fanless thermal design
- 4 GB DDR3L system memory, 32 GB onboard flash
- Windows 10 Enterprise (64-bit) preloaded; supplied with JMobile HMI runtime
- 2 x 10/100/1000 Mbit Gigabit LAN, 2 x USB 3.0, 1 x RS-232/422/485 (BIOS-configurable)
- JMobile Studio compatible — SVG vector graphics, multilanguage, alarms, recipes, scheduler, VNC remote, scripting
- IP66 front, IP20 rear; system frame ground protection (GPE)
- 24 V DC input (19.2–28.8 V DC), 1.64 A max @ 24 V DC; plastic chassis, ~1.37 kg
- Panel cutout 271 x 186 mm, faceplate 282 x 197 mm, depth 29 + 6 mm — panel or VESA mount
- CE (EN 61000-6-4 / EN 61000-6-2 industrial) and FCC
Technical Specifications
System Information
| Processor | Intel Atom x5-E3930 (Apollo Lake) SoC |
|---|---|
| System Memory | 4 GB DDR3L |
| Real-Time Clock | Yes |
| Buzzer | Yes |
| CPU Cooler (Type) | Passive (Fanless) |
| System Frame Ground Protection | GPE Design |
Storage
| Onboard Flash | 32 GB |
|---|
Panel
| LCD Size | 10.1" widescreen |
|---|---|
| Aspect Ratio | 16:9 |
| Display Type | TFT WSVGA |
| Resolution | 1024 x 600 |
| Luminance | 240 cd/m² typ. |
| LCD Colour | 16.7M |
| Active Display Area | 10.1" diagonal |
| Backlight | LED, dimmable to 0% |
| Touch Type | Resistive touchscreen |
External I/O
| Ethernet | 2 x 10/100/1000 Mbit Gigabit LAN |
|---|---|
| USB Port | 2 x USB 3.0 |
| Serial | 1 x RS-232/422/485 (BIOS-configurable) |
| DC Input | DC-in connector |
Expansion
| Expansion | Optional plug-in modules for fieldbus systems, I/O and controllers |
|---|
Power Requirement
| DC Input | 24 V DC (19.2 – 28.8 V DC) |
|---|---|
| Current Consumption | 1.64 A at 24 V DC (max.) |
Software Support
| OS | Windows 10 Enterprise (64-bit) |
|---|---|
| HMI Runtime | JMobile runtime included (eLITE610 SKU); JMobile Studio compatible |
| HMI Features | Full SVG vector graphic support with transparency / alpha blending, Data acquisition, alarm handling, scheduler and timed actions, Recipes, users and passwords, e-mail and RSS feeds, Multilanguage applications (incl. Far East languages), Remote monitoring + control with mobile clients, VNC-based remote maintenance and support, Off-line HMI application simulation, Powerful scripting language with debugging, Wide library of factory / building automation communication drivers |
Certification
| Certification Information | CE — Emission EN 61000-6-4, CE — Immunity EN 61000-6-2 (industrial environments), FCC |
|---|
Mechanical & Environmental
| Operating Temp. | -5°C ~ 50°C (23°F ~ 122°F) |
|---|---|
| Storage Temp. | -20°C ~ 70°C (-4°F ~ 158°F) |
| Operating & Storage Humidity | 5% ~ 85% relative humidity, non-condensing |
| IP Rating | IP66 (front), IP20 (rear) |
| Faceplate (L x H) | 282 x 197 mm |
| Panel Cutout (A x B) | 271 x 186 mm |
| Mounting Depth (D + T) | 29 + 6 mm (under 30 mm slim depth) |
| Weight | Approx. 1.37 kg |
| Mounting Kit | Panel mount / VESA |
| System Fan | Fanless |
| Construction | Plastic chassis |
Ordering Information
| Barebone | eLITE610 (P/N: 10IE0061000X0) — with JMobile runtime, eLITE610-NH (P/N: 10IE0061001X0) — without JMobile runtime |
|---|
