Cermate XL Series: Large Format Industrial HMI Panels for Process Visualisation

When Small HMIs Are Not Enough

A 7" or 10" HMI is ideal for a single-machine operator interface. But when your process has dozens of control loops, multiple feed streams, or a complex piping and instrumentation diagram (P&ID), operators need a larger screen to see the full picture at a glance — without scrolling between multiple screens. The Cermate XL series addresses this with 15", 17", 19", and 21.5" display options.

XL Series Specifications

• Sizes: 15", 17", 19", 21.5" TFT LCD widescreen
• Resolution: 1024×768 (15") to 1920×1080 FHD (21.5")
• Brightness: 350–500 nits
• Touch: PCAP 5-point multi-touch standard; resistive optional
• Front panel: IP65 sealed aluminium bezel
• PLC drivers: 200+ protocols — Siemens, Rockwell, Mitsubishi, Delta, Schneider, Modbus, and more
• Communication: 2× RS-232/485, 1× Ethernet, 1× USB Host, 1× SD card
• Operating temperature: 0°C to 50°C
• Operating system: Embedded Linux (EZware runtime)

Typical Applications

• Boiler and steam system visualisation
• Water treatment process overview
• Chemical batch reactor monitoring
• Building management system (BMS) interface
• Substation protection relay HMI

TSL Automation Solutions is the authorised Cermate distributor for India — supplying XL series HMIs with full technical support, EZware training, and local after-sales service. Contact us for pricing and demo units.
